| Payment & Shipping Terms | Supply Capacity | ||
|---|---|---|---|
| Unit Price: | 12.0 USD | Production Capacity: | 10,000,000pcs/Month |
| Payment Terms: | L/C, T/T, WU | Packing: | Clamshell packing |
| Min. Order: | 1 Piece/Pieces | Delivery Date: | About 30 days |
| Means of Transport: | Ocean, Air, Land | ||
Specifications
1.MYDP TO VGA HDMI adapter cable with power supply
2.It used ANX7730+ANX7732
3.The Highest resolution supports 1920*1200P 60HZ
4.VGA Output is satisfied with VESA VSIS V1r2 standard.
5.Supports hot plug
Product Introduction:
MYDP(SlimPort) to VGA+HDMI is one of video transmission with power supply.The highest transmission rate of MYDP input can up to 5.4Gbps.Input device including LG G2 mobile phone(Android system).PS:The HDMI port supports HK NEXUS 7 tablet PC(Andorid system).Both HDMI and VGA output supports 1920*1080P@60HZ resolution.Output device including HDTV,monitor.The VGA and HDMI cannot insert together.If you insert them in the same time ,the HDMI signal will output preferentially.
MYDP(SlimPort) to VGA+HDMI supports hot plug,plug and play.The inner chip should have enough power to run,so it should be connected to +5v power supply.
slimport to HDMI Cable,Connect mobile devices to any big screen.High speed micro USB(male) to HDMI(male) connector.
DisplayPort Technology:
1)SlimPort branded products are compatible with the Mobility DisplayPort standard, which is an extension of DisplayPort.
2) Use DisplayPort technology to power our SlimPort products
3) Experience an advanced digital link for sending audio and video to your display with high resolutions, up to 4K x 2K at 60Hz, all while consuming a fraction of your battery life
The Power Advantages of SlimPort:
1) There are definite power perks for people choosing SlimPort. By using a standard micro-USB cable to display your content, you'll be charging your mobile device's battery. And even if you don't have a power cable handy, SlimPort draws very little power from your device for overall low power consumption.
SlimPort Connectivity Advantages:
1) SlimPort products can connect to any display type: HDMI for TVs. Now, displaying content on a big screen has never been easier.
Faster Bandwidth:
1) Powered by DisplayPort, SlimPort enables high-bandwidth video playback, which allows your mobile device to deliver extremely high resolution in full HD media, including 3D at 1080p.
Features:
Compatible with Google LG Nexus 4 /Google Nexus 7/LG Optimus G Pro/
Fujitsu Stylistic QH582 / Asus PadFone Infinity
SlimPort to HDMI Cable, Connect mobile devices to any HDMI big screen.
Works with millions of HDMI-enabled displays, Projectors, Laptops or TVs.
Theater-quality HD Video, 3D Graphics and Audio.
Charges mobile device during playback using power adapter (not included).
Support Full HD and 3D at 1080p@60Hz.
High speed with ethernet HDMI & Slimport Certified.
