| Quantity: | |
|---|---|
| tem | Structure (mm) | Insulation Dia (mm) | Braid Coverge (%) | Approx Overall Dia (mm) |
| RG59 | 1/0.81 | 3.70 | 60% | 6.10 |
| RG59 Messenger | 1/0.81+1/1.30 | 3.70 | 60% | 6.10 |
| RG6 | 1/1.02 | 4.57 | 60% | 7.00 |
| RG6 Messenger | 1/1.02+1/1.30 | 4.57 | 60% | 7.00 |
| RG11 | 1/1.63 | 7.11 | 60% | 10.1 |
| RG11 Messenger | 1/1.63+1/1.83 | 7.11 | 60% | 10.1 |
| RG174 | 7/0.16 | 1.50 | 95% | 2.80 |
| 17 VATC | 1/1.13 | 4.85 | 60% | 6.90 |
| 19 VATC | 1/1.02 | 4.6 | 60% | 6.90 |
| KX6 | 7/0.2 | 3.70 | 70% | 6.10 |
OEM/ODM
| tem | Structure (mm) | Insulation Dia (mm) | Braid Coverge (%) | Approx Overall Dia (mm) |
| RG59 | 1/0.81 | 3.70 | 60% | 6.10 |
| RG59 Messenger | 1/0.81+1/1.30 | 3.70 | 60% | 6.10 |
| RG6 | 1/1.02 | 4.57 | 60% | 7.00 |
| RG6 Messenger | 1/1.02+1/1.30 | 4.57 | 60% | 7.00 |
| RG11 | 1/1.63 | 7.11 | 60% | 10.1 |
| RG11 Messenger | 1/1.63+1/1.83 | 7.11 | 60% | 10.1 |
| RG174 | 7/0.16 | 1.50 | 95% | 2.80 |
| 17 VATC | 1/1.13 | 4.85 | 60% | 6.90 |
| 19 VATC | 1/1.02 | 4.6 | 60% | 6.90 |
| KX6 | 7/0.2 | 3.70 | 70% | 6.10 |
OEM/ODM
