| Quantity: | |
|---|---|
COA-001
Place of Origin:
Brand Name:
Model Number:
Number of Conductors:
Product name:
Certification:
Application:
Conductor:
Insulation:
Shield:
Jacket:
Color:
Length:
Supply Ability:
600000000 Kilometer/Kilometers per Month Coaxial type rg 6 coaxial cable for CCTV CATV system
Packaging Details
Coaxial type rg59 rg11 rg58 rg213 rg174 rg 6 coaxial cable for CCTV CATV system
100Meter/Roll, 200Meter/Spool, 305Meter/Wooden, 305Meter/Plastic Reel
Port
Shanghai/Ningbo
Lead Time :
| Quantity(Meters) | 1 - 30000 | >30000 |
| Est. Time(days) | 15 | To be negotiated |
RG6
| Procuct Construction | STANDARD SHIELD | TRI-SHIELD | QUAD-SHIELD | |
CONDUCTOR | MATERIAL | BC/CCS | BC/CCS | BC/CCS |
Nom.Dia. | 18AWG | 18AWG | 18AWG | |
DIELECTRIC | MATERIAL | Foam PE | Foam PE | Foam PE |
Nom.Dia. | 4.57mm | 4.57mm | 4.57mm | |
SHIELD | MATERIAL | Al Foil+Al Braiding | Al Foil+Al Braiding+Al Foil | (Al Foil+Al Braiding)*2 |
COVERAGE | 40%-95% | 40%-95% | 40%-60% | |
JACKET | MATERIAL | PVC/PE | PVC/PE | PVC/PE |
Nom.Thick. | 0.80mm | 0.80mm | 0.86mm | |
6.91mm | 7.06mm | 7.62mm | ||
MESSENGER | MATERIAL | Galvanized steel wire | ||
Nom.Dia. | 1.30mm | 1.30mm | 1.30mm | |
Nominal Impedance(ohm) | 75±3 | ||
Nominal Velocity of propagation(%) | 85 | ||
Nominal Capacitance(pf/m) | 50 | ||
Spark Test(VAC) | 3000 | ||
SRL(dB) | 20 | 20 | |
Attenuation [68°F(20℃)] | Frequency(MHz) | Maximum(dB/100ft) | Maximum(dB/100m) |
5 | 0.58 | 1.9 | |
55 | 1.6 | 5.25 | |
187 | 2.85 | 9.35 | |
300 | 3.55 | 11.64 | |
450 | 4.4 | 14.43 | |
600 | 5.1 | 16.73 | |
750 | 5.65 | 18.54 | |
865 | 6.1 | 20.01 | |
1000 | 6.55 | 21.49 | |
