Factory Price Bare Copper Conductor PVC PE Jacket RG11 Coaxial Cable for CCTV MATV CATV System Communication Cable
Description： . Standard Mil-c-17 . Equivalent to :SYWV-75-7(GB Standard) . Insulation Material: Foam PE . Impedance:75Ω±3 . Color: Black, White
Typical Application: RG-11/U is a specific type of coaxial cable, It is used in direct burial applications. The characteristic impedance of RG11 is 75 ohms, and the capacitance is around 53F/m.
Best Feature: Lower signal loss than smaller diameter cable such as RG179,RG59A/U,RG59B/U
Characteristics
Name
Specification
RG11/U coaxial cable specifications
Material of Inner Conductor
Bare Copper, CCS
Structure of Inner Conductor
1/1.63mm
Material of Insulation
Foam PE
Diameter of Insulation
7.11mm
1st Shielding
Aluminum Foil
Material of Braiding(2nd Shielding)
CCA, Bare Copper, Tinned Copper
Structure of Braiding
128*0.15mm
Material of Jacket
PVC
Diameter of Jacket
10.20mm
Working temp
-40℃/80℃
Impedance
75Ω±3
Max Operating Voltage
5000V
Productor Details
Note: Other configurations, sizes, colors and length not specified herein are available upon request.
PS:Pictures are taken on the basis of physical objects to ensure authenticity.
Product Description
Note: Price is based on the salesman's quotation.
Coaxial Cable
Description： . Standard Mil-c-17 . Equivalent to :SYWV-75-7(GB Standard) . Insulation Material: Foam PE . Impedance:75Ω±3 . Color: Black, White
Typical Application: RG-11/U is a specific type of coaxial cable, It is used in direct burial applications. The characteristic impedance of RG11 is 75 ohms, and the capacitance is around 53F/m.
Best Feature: Lower signal loss than smaller diameter cable such as RG179,RG59A/U,RG59B/U
Characteristics
Name
Specification
RG11/U coaxial cable specifications
Material of Inner Conductor
Bare Copper, CCS
Structure of Inner Conductor
1/1.63mm
Material of Insulation
Foam PE
Diameter of Insulation
7.11mm
1st Shielding
Aluminum Foil
Material of Braiding(2nd Shielding)
CCA, Bare Copper, Tinned Copper
Structure of Braiding
128*0.15mm
Material of Jacket
PVC
Diameter of Jacket
10.20mm
Working temp
-40℃/80℃
Impedance
75Ω±3
Max Operating Voltage
5000V
Productor Details
Note: Other configurations, sizes, colors and length not specified herein are available upon request.
PS:Pictures are taken on the basis of physical objects to ensure authenticity.
