Free Samples Hd Tv Cable Dual Coaxial Cable 540 With 2C Power Cable Optional

Availability:
Quantity:
Inquire Add to Basket

  • COA-039

Product Description
Product Name
Coaxial Cable RG59 RG6 RG8 RG11
Conductor Material
Bare Copper, CCA, CCS(18% 21%）
Function
CCTV CATV HDTV Satellite
Package
100M 305M  Wooden Durm, Plastic Drum. Easy Pull-Out Carton

  • RG59 Coaxial Cable

Conductor OD : 0.81mm
Conductor Material: Bare Copper,CCS
Insulation: FPE 3.1MM
Shield 1:AL Foil, Bonded Al Tape
Shield 2: AL/CCA Brading Net     64/80/96/112/128x0.12mm
Jacket: PVC 6.1MM
RG6 Coaxial Cable

Conductor OD : 1.02mm

Conductor Material: Bare Copper,CCS

Insulation: FPE 4.8 MM

Shield 1:AL Foil, Bonded Al Tape

Shield 2: AL/CCA Brading Net 64/80/96/112/128x0.12mm

Jacket: PVC 6.8MM
RG8U Coaxial Cable

IMPEDANCE : 50 Ohm
Conductor OD : 2.74mm

Conductor Material: CCA/CCS

Insulation: FPE 7.24 MM

Shield 1: Bonded Al Tape

Shield 2: AL/CCA Brading Net 128x0.12mm

Jacket: PE 10.3MM

RG11 Coaxail Cable

IMPEDANCE : 75 Ohm

Conductor OD : 1.63mm

Conductor Material: CCS

Insulation: FPE 7.11 MM

Shield 1: Bonded Al Tape

Shield 2: AL/CCA Brading Net 128x0.12mm

Jacket: PE 10.1MM
Coaxial Cable With Power Cable

RG58 RG59 RG6 With Power Siamese
Power Cable: 2 Core
Conductor material:  Bare Copper, CCA
Size:  2x10x0.15mm
         2x10x0.18mm
         2x15x0.15mm
         2x15x0.18mm
  Power Supply 12V and 24V
Coaxial Cable With Steel Messenger
RG6 With Steel, 1.0/1.2mm
RG11 with Steel 1.5mm
