High Quality 3x1 HDMI Switcher

Quantity:
Payment & Shipping Terms Supply Capacity
Trade Term: FOB Production Capacity: 30,000PCS per month
Payment Terms: L/C, T/T, WU Packing: optional
Min. Order: 1000 pcs Delivery Date: 30days
Means of Transport: Ocean, Air, Land

HDMI Swither, HDMI Video Switch, HDMI Splitter Switch, HDMI Splitter, HDMI Extender, HDMI Converter manufacturer and factory in China. We can produce HDMI Cable, HDMI Swither, HDMI Video Switch, HDMI Splitter Switch, HDMI Splitter, HDMI Extender, HDMI Converter according to your requirements. More types of HDMI Cable, HDMI Swither, HDMI Video Switch, HDMI Splitter Switch, HDMI Splitter, HDMI Extender, HDMI Converter wanted, please contact right now!


1.0  INTRODUCTION


This is an intelligent HDMI 3X1 Amplifier Switcher. It allows three HDMI source devices switched into one HD monitor or projector. Adopted touch button design lets you enjoy the high technology and easy switching life. This intelligent Switcher is quite different from other switchers. It has one input port on the front panel. This not only reduced the switcher to an ideal small size but also be more convenient for users to connect the source devices.


1.1 INTELLIGENT FUNCTION


1)  When supplied with power, this switcher will select the power-on source device depending on the sequence automatically (input1>input2>input3)

2) Once the source device is turned on or plugged in (should stay power-on mode), the switcher will automatically select this source.

3) Once the source device is turned off or plugged out, the switcher will automatically select the next power-on source depending on the sequence (input1>input2>input3)

4) Once the touch button been touched, this switcher will automatically select the next power-on source depending on the sequence (input1>input2>input3)

Note:

1) When the source devices are on the stand-by mode, its power supply should be turned off, otherwise this switcher can not meet intelligent function.

2) When plugged in or out, this switcher is completely intelligent.

1.2 FEATURES

This HDMI Amplifier Switcher has many features that enable it to perform in a superior manner. Among those features you will find:

One input port on the front panel is specialized for portable devices

Multi-switching methods: intelligent, IR remote or by touch button

Supports highest video resolution 1080p.

Supports 250MHz/2.5Gbps per channel (7.5Gbps all channel) bandwidth.

Supports 12bit per channel (36bit all channel) deep color.

HDCP pass-through.

lSupports uncompressed audio such as LPCM.

lSupports compressed audio such as DTS Digital, Dolby Digital(including DTS-HD and Dolby  True HD).

l  Support 3D all format, including 1080p @ 23.98/24Hz, 720p @ 59.94/60Hz/50Hz, bandwidth up to 250MHz.


Category: HDMI Splitter & HDMI Switch & HDMI Extender
