High Quality Dual RG174 Coaxial Cable

Quantity:
Payment & Shipping Terms Supply Capacity
Unit Price: 0.2 USD Production Capacity: 10,000,000m/month
Trade Term: FOB,CFR,CIF,CIP Packing: Plastic Reel or Wooden...
Payment Terms: L/C, T/T, WU Delivery Date: About 25 days
Min. Order: 10000 Meter
Means of Transport: Ocean, Air, Land

High Quality Coaxial Cable Dual RG174 / RG174 Dual cable / RG174 Twin Cable

1. Specifications:
1) 2x(7x0.16mmBare Copper+1.52mmFoamedPE+A/P/A+60%TinnedCopperBraiding +2.54mmPVC)
2) Customers' specifications are welcomed

2. Characteristics:
Impedance: 50+/-2 Ohm
Velocity of Propagation: 85%
Capacitance: 110pF/m
Return Loss: 20dB min
Attenuation: [@68 F. (20 C) ] dB/100meters
1MHz: 1.9dB 1000MHz: 25.94dB
10MHz: 2.92dB 1200MHz: 28.60dB
50MHz: 5.49dB 1450MHz: 31.65dB
100MHz: 8.13dB 1800MHz: 35.56dB
200MHz: 11.25dB 2250MHz: 39.62dB
400MHz: 16.01dB
700MHz: 21.52dB
900MHz: 24.53dB

3. Packing:
1) Packing Lengths:
100m/roll, 200m/roll, 305m/roll.
Other lengths available according to client's Request;
2) Inner packing: Wooden reel, plastic reel.
3) Outer packing: Carton box, pull box, pallet.
4) Other packing available according to client's Request.

Attenuation [@68o F. (20o C. )]
Frequency (MHz) Nom. (dB/100 ft. )
10 2.99
100 9.50
400 22.57
1000 36.60
2000 51.85
3000 64.05
RG174 Coaxial Cable

Construction

Center Conductor: 7X0.16 BC/CCS
Dielectric: 1.90mm Solid PE
Braid Coverage: 90% TC
Jacket: 2.7+0.10mm PVC
Jacket Thickness: 0.5mm

Category: Coaxial Cable

Related Category: DVI Cable  DisplayPort Cable  Computer Cable  Speaker Cable  Patch Cord Cable

Payment & Shipping Terms Supply Capacity
Unit Price: 0.2 USD Production Capacity: 10,000,000m/month
Trade Term: FOB,CFR,CIF,CIP Packing: Plastic Reel or Wooden...
Payment Terms: L/C, T/T, WU Delivery Date: About 25 days
Min. Order: 10000 Meter
Means of Transport: Ocean, Air, Land

High Quality Coaxial Cable Dual RG174 / RG174 Dual cable / RG174 Twin Cable

1. Specifications:
1) 2x(7x0.16mmBare Copper+1.52mmFoamedPE+A/P/A+60%TinnedCopperBraiding +2.54mmPVC)
2) Customers' specifications are welcomed

2. Characteristics:
Impedance: 50+/-2 Ohm
Velocity of Propagation: 85%
Capacitance: 110pF/m
Return Loss: 20dB min
Attenuation: [@68 F. (20 C) ] dB/100meters
1MHz: 1.9dB 1000MHz: 25.94dB
10MHz: 2.92dB 1200MHz: 28.60dB
50MHz: 5.49dB 1450MHz: 31.65dB
100MHz: 8.13dB 1800MHz: 35.56dB
200MHz: 11.25dB 2250MHz: 39.62dB
400MHz: 16.01dB
700MHz: 21.52dB
900MHz: 24.53dB

3. Packing:
1) Packing Lengths:
100m/roll, 200m/roll, 305m/roll.
Other lengths available according to client's Request;
2) Inner packing: Wooden reel, plastic reel.
3) Outer packing: Carton box, pull box, pallet.
4) Other packing available according to client's Request.

Attenuation [@68o F. (20o C. )]
Frequency (MHz) Nom. (dB/100 ft. )
10 2.99
100 9.50
400 22.57
1000 36.60
2000 51.85
3000 64.05
RG174 Coaxial Cable

Construction

Center Conductor: 7X0.16 BC/CCS
Dielectric: 1.90mm Solid PE
Braid Coverage: 90% TC
Jacket: 2.7+0.10mm PVC
Jacket Thickness: 0.5mm

Category: Coaxial Cable

Related Category: DVI Cable  DisplayPort Cable  Computer Cable  Speaker Cable  Patch Cord Cable
