High Quality S-video to HDMI Cable with Nylon Mesh

High Quality S-video to HDMI Cable with Nylon Mesh

• V1.4 HDMI cable high speed with Ethernet

• 19-pin male to male

• Metal shell with black braiding

• Inside conductor of cable: pure oxgen-free copper

• Connector: 24K gold-plated

• Cable compatible: 42awg,38awg,34awg,30AWG, 28AWG, 26AWG, and 24AWG

• Length: available from 0.5 to 20m

• Compatible with HDMI 1.2a, 1.3b, 1.3c,1.4, HDCP, and FCC,CE&RoHS ,REACH

• Supports full 1,080p,1440P,1600P ,2160P

• Supports 3D,4KX2K,ARC(Audio Return Channel)

• Triple Shielding



  Festures and structure of HDMI cable:

  Center conductor :high quality digital signal delivered by oxygn-free copper

  Insulation:Using foamed PE as the insulation,ensure image quality and transmit image signal with stability.

  Inner shield:100% Aluminum/Mylar foil shield,prevent high frequency noises and interference

  Outer shield:95% copper braid shield,prevents most low frenquency noises and interference.

  HDMI cable is suitable for HDTV,home themter,DVD player,projector,PS3,XBOX 360 and other HDMI devices.

  High density triple shielding for maximum rejection of EMI and RFI

  Transfer speed of 10.5Gbps.

  Electrical:
  100% open and short test
  Voltage: 300V DC, 5MΩ /10ms
  Insulation resistance: 10MΩ Minimum
  Contact resistance: 2Ω Maximum
  Working temperature: -25 to 80 degree Celsius

• Item	High Speed HDMI cable with ethernet
  Connector	Full 19pin HDMI port 24k gold plated
  Connector type	Type A
  Plug mould	PVC injection mould, bi-color mould, metal shell mould
  Gender	Male
  conductor	Full oxygen-free pure copper
  Wire gauge	AWG24, AWG26, AWG28, AWG30
  Cable jacket	PVC
  Support	1080P, 3D, ethernet, 4K, audio return channel
  Application	HDTV, DVD player, set top box, xbox360, ps3, satellite, home studio^
  Packing	1. Polybag, blister packaging etc
  	2.According to customers.
